AWA SWA Armoured Aluminium Conductor Cable 0.6/1kV IEC60502 NA2XRH
APPLICATION
• For fixed installation of the transmission and distribution systems, tunnels and pipelines and other occasions
• For situation not suppose to bear the external mechanical force
CONSTRUCTION
Conductor : Aluminium
Insulation :XLPE
Filler :LSZH
Armour :Single core: AWA (Aluminium wire armour) All other sizes: SWA (Galvanized round steel wire)
Sheath :LSZH
STANDARD
EN 60502-1
CHARACTERISTICS
Voltage Rating Uo/U 0.6/1kV
Temperature Range Fixed: -5°C to +90°C
SPECIFICATION
|
Cross Sectional Area
|
class of conductor
|
Maximum DC
|
Maximum Permissible Current Rating Amp
|
|
Resistance of Conductor
|
Nominal Overall Diameter of Cable
|
|
Trefoil in Ground@20°C
|
Trefoil in Air @30°C
|
|
|
mm²
|
No. x mm
|
Ù/km
|
mm
|
A
|
A
|
|
1 - Core
|
|
1 x 16
|
2
|
1.91
|
9.4
|
86
|
66
|
|
1 x 25
|
2
|
1.2
|
11.2
|
106
|
103
|
|
1 x 35
|
2
|
0.868
|
12.4
|
130
|
129
|
|
1 x 50
|
2
|
0.641
|
13.9
|
161
|
159
|
|
1 x 70
|
2
|
0.443
|
16.1
|
204
|
206
|
|
1 x 95
|
2
|
0.32
|
18
|
252
|
253
|
|
1 x 120
|
2
|
0.253
|
20
|
295
|
296
|
|
1 x 150
|
2
|
0.206
|
22.2
|
339
|
343
|
|
1 x 185
|
2
|
0.164
|
24.4
|
395
|
395
|
|
1 x 240
|
2
|
0.125
|
27.5
|
472
|
471
|
|
1 x 300
|
2
|
0.1
|
30.3
|
547
|
547
|
|
1 x 400
|
2
|
0.0778
|
33.9
|
643
|
663
|
|
1 x 500
|
2
|
0.0605
|
37.9
|
754
|
770
|
|
1 x 630
|
2
|
0.0469
|
42.3
|
882
|
899
|
Contact us for more details
